JE Pistons Premium Race Series Piston Rings JG1004-3250
JE Pistons Premium Race Series Piston Rings JG1004-3250
6 in stock
Couldn't load pickup availability
Product Description
JE Piston Rings are designed to maximize horsepower through precision sealing of combustion pressure. They are offered in a huge selection of sizes, various materials, and in multiple thicknesses to suit a wide variety of engines. JE Pistons also offers an array of custom piston ring services including back cutting, dyke cutting, lapping, grinding, and PVD coating. These services, the same used by top NHRA Pro Stock and NASCAR teams, are now available to the public and offer tremendous gains in durability, power through reduced friction, and improved ring seal.
These JE Pistons Premium Race series piston rings offer unbeatable performance. They feature high-quality materials suitable for high-horsepower needs. When you need performance, JE Pistons has you covered.
Extended Description
- Piston Ring Set, 4 Cyl., File Fit, 0.0394 in. Carbon Steel Nitride Top Ring, 0.0472 in. Ductile Iron Phosphate Second Ring, 0.1102 in. Carbon Steel Nitride Low Tension Oil Ring, Each.
Application Summary
Part Type
Engine Piston Ring Set
description
| aaia_ |
Engine Piston Ring Set |
|---|---|
| market_ |
JE Piston Rings are designed to maximize horsepower through precision sealing of combustion pressure. They are offered in a huge selection of sizes, various materials, and in multiple thicknesses to suit a wide variety of engines. JE Pistons also offers an array of custom piston ring services including back cutting, dyke cutting, lapping, grinding, and PVD coating. These services, the same used by top NHRA Pro Stock and NASCAR teams, are now available to the public and offer tremendous gains in durability, power through reduced friction, and improved ring seal. |
| product_ |
Piston Ring Set, 4 Cyl., File Fit, 0.0394 in. Carbon Steel Nitride Top Ring, 0.0472 in. Ductile Iron Phosphate Second Ring, 0.1102 in. Carbon Steel Nitride Low Tension Oil Ring, Each. |
| product_ |
Piston Ring Set, 4 Cyl., File Fit, Each. |
| product_ |
Piston Ring Set |
s_item
| department | Engines & Components |
|---|---|
| section | Pistons & Piston Rings |
| name | JE Pistons Premium Race Series Piston Rings JG1004-3250 |
| brand | JE Pistons |
| price | 131.54 |
| blurb | Piston Rings, Gas Nitrided, 3.250 in. Bore, 1.0mm, 1.2mm, 2.8mm Thickness, 4-Cylinder, Set |
| title | JE Pistons Premium Race Series Piston Rings |
| description | These JE Pistons Premium Race series piston rings offer unbeatable performance. They feature high-quality materials suitable for high-horsepower needs. When you need performance, JE Pistons has you covered. |
item_row
| handle | JEP-JG1004-3250 |
|---|---|
| item_ |
298052 |
| brand_ |
125 |
| brand_ |
JE Pistons |
| item_ |
https://d5otzd52uv6zz.cloudfront.net/dd275486-6ac3-4a3c-83aa-509e05fc41e8-100.jpg |
| item_ |
JG1004-3250 |
| item_ |
JE Pistons Ring Sets 1.0-1.2-2.8-3.250 |
| item_ |
Engine Components |
| item_ |
Piston Rings |
| item_ |
193564241511 |
| item_ |
131.54 |
| item_ |
|
| t14_ |
4 |
| mfr_ |
|
| dim_ |
0.20 |
| dim_ |
4.50 |
| dim_ |
4.20 |
| dim_ |
1.70 |
| shipping_ |
14.52 |
| item_ |
jepJG1004-3250 |
| taxonomy_ |
5372 |
| collection_ |
|
| collection_ |
|
| status | Active |
| item_ |
1 |
| productTaxonomy | 5372 |
Overview
| Brand | JE Pistons |
|---|---|
| Notes | Barrel face back cut neutral top ring, Napier back cut neutral second ring with full seal flex vent style oil ring. |
| Gapless | No |
| File Fit | No |
| Quantity | Sold as a set. |
| Bore (mm) | 82.550mm |
| Part Type | Piston Rings |
| Bore (in.) | 3.250 in. |
| Gas Ported | No |
| Product Line | JE Pistons Premium Race Series Piston Rings |
| Oil Ring Tension | Low |
| Oil Ring Included | Yes |
| Oil Ring Material | Nitride coated carbon steel |
| Top Ring Included | Yes |
| Top Ring Material | Steel |
| Oil Ring Thickness | 2.8mm |
| Top Ring Thickness | 1.0mm |
| Second Ring Included | Yes |
| Second Ring Material | Ductile iron |
| Second Ring Thickness | 1.2mm |
| Top Ring Facing Material | Gas nitrided |
| Manufacturer's Part Number | JG1004-3250 |
| Second Ring Facing Material | Phosphate coated |
